Position: - > Air-cooled Diesel Generators |
![]() |
Back>> |
 |
| Model: BN12000DCE |
|
|
Model |
BN12000DCE |
BN12000DCE |
|
Engine model |
BN290F/E |
BN290F/E |
|
Rated frequency (Hz) |
50 |
60 |
50 |
60 |
|
Rated voltage (V) |
230 |
240/120 |
400/230 |
400/230 |
|
Rated current (A) |
43 |
50 |
19 |
21 |
|
Rated output power (Kw) |
10 |
12 |
10 |
12 |
|
Max.output power (Kw) |
11 |
13 |
11 |
13 |
|
Type |
2-cylinder/air-cooled/4-stroke/direct injection |
|
Bore¡ÁStroke©zmm©{ |
90¡Á75 |
|
Cylinder number |
2 |
|
Compression ratio |
19£º1 |
|
Starting system |
Recoil starter/E-starter |
|
Rotation direction |
clockwise |
|
Fuel consumption£¨g/kw.h) |
£¼200 |
|
Oil consumption£¨g/KW.h) |
2.6 |
|
Displacement |
0.954 |
|
Lubrication system |
pressure splashed |
|
Rated rotation speed (rpm) |
3000/3600 |
|
Power factor (cosØ) |
1 |
0.8 |
|
Phase |
Singel phase |
Three phase |
|
Structure type |
open-frame type
¡¡
¡¡
¡¡
|
|
Starting system |
Recoil starter/Electric starter |
|
Fuel tank capacity(L) |
60 |
|
Oil capacity(L) |
3 |
|
Noise level (dB) |
98 |
|
Net weight (Kg) |
260 |
|
Gross weight(Kg) |
270 |
|
Overall dimension (mm) |
1050¡Á680¡Á750 | |
|
|
